Mandyoc
The facts below are what the maker publishes about Mandyoc, checked and dated. Our editors have not written about it yet.
The facts
Each one read from Mandyoc's own pages, with the date it was checked.
What it does
- 3D visuals
- Yeschecked 24 Sep 2026
- Configuration
- The parameter file configures options including solver type, particle advection, surface tracking, viscosity, and simulation time limits.checked 11 Oct 2026
- Container
- The project provides a Docker container image for Mandyoc.checked 12 Oct 2026
- Delivery mode
- desktopchecked 24 Sep 2026
- Dependency
- Mandyoc requires the PETSc library to run.checked 11 Oct 2026
- Dimensions
- The implementation uses hexahedral elements for three-dimensional grids and quadrilateral elements for two-dimensional grids.checked 11 Oct 2026
- Documentation and examples
- The documentation includes installation instructions, parameter and input file descriptions, applications, examples, and benchmark studies.checked 12 Oct 2026
- Examples
- The repository's examples include Jupyter notebooks with explanations and instructions for running experiments.checked 11 Oct 2026
- Inputs
- Initial temperature, velocity, and model interface geometry can be supplied using ASCII input files.checked 12 Oct 2026
- License
- Mandyoc is free software distributed under the BSD 3-clause License.checked 12 Oct 2026
- Notable limitation
- The installation guide says Mandyoc currently supports PETSc up to v3.24.5 and advises against versions above v3.25.checked 12 Oct 2026
- Numerical method
- It uses the finite element method, with hexahedral elements for 3D grids and quadrilateral elements for 2D grids.checked 12 Oct 2026
- Particles
- The code tracks composition by placing particles in finite elements and advecting them according to nearby node velocities.checked 12 Oct 2026
- Physics
- The model solves conservation equations for mass, momentum, and energy using a non-Newtonian fluid formulation and the Boussinesq approximation.checked 12 Oct 2026
- Purpose
- Mandyoc is a finite element code built on PETSc to simulate thermo-chemical convection of Earth's mantle.checked 12 Oct 2026
- Rheologies
- It supports different linear and non-linear rheologies to simulate strain and stress patterns in Earth's crust and mantle during extension or collision.checked 11 Oct 2026
- Rheology
- The code supports different linear and non-linear rheologies for simulating strain and stress patterns in the crust and mantle.checked 12 Oct 2026
- Rheology features
- Its documented options include visco-plastic deformation, Byerlee or Drucker-Prager plasticity criteria, and temperature-based or power-law viscous rheology.checked 11 Oct 2026
- Rheology options
- Available options include plastic yield criteria and viscous rheologies such as Frank-Kamenetskii and power-law models.checked 12 Oct 2026
- Support
- The project directs users to GitHub discussions and issues and lists support contacts [email protected] and [email protected].checked 12 Oct 2026
- Supported operating systems
- The documented installation steps work on Linux and macOS; the project says installation on Windows has not been tested.checked 11 Oct 2026
- Surface processes
- Configuration options allow free-surface tracking and erosion and sedimentation simulation.checked 12 Oct 2026
Money
- Free plan
- Yeschecked 24 Sep 2026
Where it runs
- Platforms and dependencies
- The installation instructions support Linux and macOS; Windows installation has not been tested, and building requires PETSc, gcc, and make.checked 12 Oct 2026
